Optional equipment
Precision Seed Drills
MAXIMA 2
125
Machine use
Only one spring (1) can be positioned in the centre of the
parallelogram. The second spring (2) can be fitted on the
right side of the parallelogram.
5. Covering scraper
Kit no. 1676761
The covering scrapers transfers soil in the sowing line for
easier furrow closing.
Adjustment
Lateral adjustment
- Unscrew the 4 bolts (1).
- Centre scrapers (2) with regards to the furrow.
- Tighten the 4 bolts (1).
This equipment does not allow the seeding
unit to be locked in the raised position.
A 82 mm (3.2’’) spacer is delivered with this
equipment.
Check setting over the first few metres sown.
