Precision Seed Drills
118
MAXIMA 2
Optional equipment
1. Clod clearer
Kit no. 1676801
Clod clearer with disk coulter for gauge wheels (a).
Kit no. 1676802
Clod clearer with disk coulter for gauge wheels (b).
The clod clearer is used to clear clods and small stones
to prepare for the passage of the lateral gauge wheels
and create a furrow in humid soil after having pushed
away the dry and clody part.
Adjustments
Height adjustment
- Loosen screws (1).
- Set the required height:
• Clod clearer (2) must be set high enough to prevent
seeding unit from engaging in the soil.
• The independent knife coulter (3) enables preparing
the passage for the coulter and facilitates its
engagement in the soil.
- Tighten screws (1).
Lateral adjustment
- Unscrew the 4 bolts (1).
- Centre clod clearer (2) with regards to the seeding
line.
- Tighten the 4 bolts (1).
We recommend adjusting the clod clearer at
approximately 20 mm (0.78’’) from the ground.
Adjust all seeding units to the same settings.
