Putting into service
Precision Seed Drills
MAXIMA 2
63
- Attach top link with hitch pin.
- Use tractor and machine attachment holes to adjust
the top link position.
- Raise machine using the tractor lift linkage until
parking stands no longer rest on the ground.
Hydraulic connections
Connect hydraulic hoses (1) and (2) to a double acting
outlet.
Hoses (A) and (B) supply the side marker
folding/unfolding cylinders.
To obtain optimum PTO shaft angles and
tractor lift capacity, the top link must be
parallel to the lower links or slightly pointing
downwards towards the tractor.
