Precision Seed Drills
62
MAXIMA 2
Putting into service
- Remove lynch pin (1) and pin (2).
- Raise parking stand (3).
- Insert pin (2) and lock using lynch pin (1).
- Repeat procedure on the other parking stand.
For attachment category 3:
- Lower the tractor three-point linkage.
- Position ball joints of tractor lower links in line with
holes of machine lower yokes.
- Insert pins (1) and lock using lynch pins (2).
- Remove lynch pin (1) and pin (2).
- Raise parking stand (3).
- Insert pin (2) and lock using lynch pin (1).
- Proceed the same way on each parking stand.
