Optional equipment
Precision Seed Drills
MAXIMA 2
173
Adjusting the application depth
- Raise the machine.
- Remove lynch pin (1) and pin (2).
- Insert pin (2) in one of bracket (3) holes to set the
required working depth.
- Insert and lock lynch pin (1).
Adjust all applicators to the same setting.
Adjusting the plates
- Loosen nut (1).
- Set plate (2) as close as possible to the disks but
without touching it. Rotate disk once to check that it is
not in contact.
- Tighten nut (1).
Repeat procedure on each applicator.
Applicators with standard coulters
Lateral adjustment
The applicator (D) is factory offset with regards to the
seeding line by approximately 50 mm (1.97’’).
The seeding unit setting must be adjusted
according to the sowing conditions (Soil
preparation and nature).
