Instructions for transport
Precision Seed Drills
MAXIMA 2
71
$INSTRUCTIONS FOR TRANSPORT
1. Putting the machine into transport
position
From the working position:
If the machine is fitted with a fertilizer or if the
machine is fitted with a fertilizer with a 1350 L
(356 US gal) hopper:
- Activate cylinders to fold side markers.
- Lock side markers using valves (1) (1 on each
marker).
- Position pin (1) in lower hole (2).
Before placing the machine into transport
position:
Wait until the rotating parts have come to a
complete stop.
this position enables leaving the marker disks (3)
pointing outwards.
