Precision Seed Drills
190
MAXIMA 2
Optional equipment
Working depth adjustment
- Loosen bolts (1).
- Position track eradicators in the required position.
- Tighten screws (1).
- Proceed the same way on the other side.
Share replacement
- Remove bolt (1) and nut (2).
- Remove and replace the worn coulter
- Reinstall bolt (1) and nut (2).
• Torque: 8.1 daN m (59 lbf ft).
33. Marker working depth limitors
Kit no. 1676815
This equipment enables limiting the marker working
depth in loose soil.
Adjust track eradicator working depth in
order to eliminate the tracks made by the
tires on the ground.
Share Part no. B0000573
