KUHN MAXIMA 2 - Setting the Seeding Unit in High Position

Instructions for work
Precision Seed Drills
MAXIMA 2
107
Setting the seeding unit in high position
- Disengage the unit using knob (1).
- Position spring (1) behind part (2).
- Lock (3) comes into contact with stop (4).
- Raise machine using tractor lift.
- Position a wedge (1) approximately 15 cm (5.90")
thick underneath the seeding unit.
The high position setting of the seeding units
enables sowing on 1 row out of 2.
