Precision Seed Drills
160
MAXIMA 2
Optional equipment
Man. calibration
After having preset the microgranulator, it is necessary
to carry out a calibration test to know the real product
volume applied.
Preparing the machine:
- Divert a product transfer tube (1) towards a container.
- Position a container (2) underneath the metering unit.
Checking flow rate:
- Travel a distance of 100 m (328’1’’) for the drive shaft
(1) to rotate 64 times which corresponds to
100 m (328’1’’) linear.
The flow can vary according to the product,
the ambient temperature and the humidity
level.
Proceed with regular calibration tests to check
the fertilizer is properly adjusted.
