Optional equipment
Precision Seed Drills
MAXIMA 2
121
3. Star shaped trash remover
Kit no. 1676783
The star-shaped trash remover is used to push aside
plant residues in order to prepare for the passage of the
seeding unit.
Adjustments
Height adjustment
- Remove lynch pin (1).
- Adjust working height using pin (2).
The working height can be adjusted to 10 different
positions.
- Insert and lock lynch pin (1).
The adjustment range is of 82.5 mm (3.25’’).
