Optional equipment
Precision Seed Drills
MAXIMA 2
159
Adjusting the outlet opening
- Loosen knob (1).
- Position adjustment lever tip (2) on the required value.
- Tighten knob (1)
Adjusting the distribution shaft rotational speed
- Remove lynch pins (1).
- Position sprockets recommended in the adjustment
charts in the adequate position:
• Drive gearwheel (a).
• Driven gearwheel (b).
- Insert lynch pins (1).
Refer to the adjustment chart to determine the
outlet opening adjustment index according to the
required volume per hectare and the spacing
between the seed drill rows.
The values indicated in the adjustment chart
are only for your information.
Refer to the adjustment chart to determine the
drive gearwheel/driven gearwheel matching set
according to the required volume per hectare
and the spacing between the seed drill rows.
Position non-used gearwheels on holder (2).
