Precision Seed Drills
30
MAXIMA 2
Machine specifications
$MACHINE SPECIFICATIONS
1. Description and glossary
0
1 : Pull bar 2 : Three-point hitch coupler
3 : Vacuum turbine 4 : Drive wheel
5 : Sowing component 6 : Gearbox
7 : Side marker 8 : Parking stand
9 : Seeding unit hopper 10 : Control hatch
11 : Distribution disc 12 : Selector
13 : Sowing depth adjustment handle 14 : Gauge wheel
15 : Press wheel 16 : Pressure spring
