KUHN MAXIMA 2 - Page 142

Precision Seed Drills
140
MAXIMA 2
Optional equipment
 Maintenance
Greasing (Every 50 hours)
- The tamping wheel pivot pin.
Replacing the scraper plates
- Remove nut (1).
- Remove screw (2) and washer (3).
- Turn plate over or replace it if necessary.
- Reinstall screw (2), nut (1) and washer (3).
Scraper plate Part no. K3600550.
