Precision Seed Drills
142
MAXIMA 2
Optional equipment
Adjusting the tamping pressure
Lever (1) enables adjusting the tamping pressure.
- Position lever (1) in one of the adjusting catches 5:
• To reduce the tamping pressure in F, move
adjustment lever (1) frontwards.
• Mover adjustment lever (1) rearwards to increase
tamping pressure in F.
Grease (Every 50 hours)
- The tamping wheel pivot pin.
