Precision Seed Drills
150
MAXIMA 2
Optional equipment
Description and glossary
Technical specifications
0
1 : Cover 2 : Sieve
3 : Hopper 4 : Distribution
5 : Emptying lever 6 : Outlet opening lever
7 : Driven shaft 8 : Drive shaft
9 : Gearwheel storage 10 : Herbicide spreading
11 : Application of slug pellets behind the roller 12 : Application of slug pellets in front of the roller
13 :
Application of slug pellets on the furrow bottom
14 : Application of insecticide on the furrow bottom
MAXIMA
Insecticide microgranulator
Part number
A
D00835A0
B
D00220B0
C
D00222B0
