Kyocera TASKalfa 181 - Job Accounting Mode

2KJ/2KH
1-5-36
4. Remove two screws and release six hooks
and two both, and then remove the right
middle cover.
Figure 1-5-60
5. Remove two screws and remove the shield
cover.
Figure 1-5-61
Right lower cover
Right lower
cover
Screw
Screw
Hook
Hook
Hook
Hook
Hook
Hook
Both
Both
Shield cover
Screw
Screw
