LaserLine Flatwork Ironer Series User Manual

Operating Principles GL16
5-2
Main Electrical Box
The following electrical components are located inside the main electrical box.
NOTE: The power supplied to the unit must match the requirements listed on the
nameplate.
Figure 5-1: Main Electrical Box. Refer to the schematics for interconnection.
FU1
120 VAC Control
Circuits
Ground
HLT1
24 VAC
Control
Circuits
FU2
FU3
