GL16 Troubleshooting
6-3
WARNING
Only trained personnel with experience in
electrical or mechanical repair should
troubleshoot and repair the unit.
Troubleshooting
WARNING
Read the REPAIR chapter and make sure
that the power is disconnected before
doing any repairs.
6.6 Heating System (cont.)
Pilot Ignition
GAS Switch Indicator Lamp Does Not Come On
When GAS Switch is Turned to ON ................................................................... 6-16
IGNITION Indicator Lamp Does Not Come On ........................................................ 6-16
GAS VALVE Indicator Lamp Does Not Come On,
IGNITION Indicator Lamp Comes On ................................................................ 6-17
Ignition Transformer: Not Operating Correctly.......................................................... 6-17
Front Panel FLAME SIGNAL Strength Voltmeter
Registers < 6 VDC ............................................................................................. 6-17
Pilot Flame: Partial or Lazy ...................................................................................... 6-18
Burner Ignition
Flame Does Not Travel Down the Entire Length of the
Burner Within 10 Seconds After Ignition ............................................................ 6-21
Touchless Temperature Sensors Operating Incorrectly............................................ 6-21
Gas Flow: Poor, Irregular, None ............................................................................... 6-21
Burner Starts Normally, Then Shuts Down ............................................................... 6-22
Burner Transfer Ignition
Burner Shuts Down .................................................................................................. 6-23
Burner Operation
Ironing Section Heats to SET Temperature, but
Will Not Ignite a Second Time ............................................................................ 6-24
Temperature HIGH LIMIT Indicator Lamp Comes On
and Shuts Down the Heating System Since the
Ironing Cylinder Temperature is Too Hot............................................................ 6-24
TEMPERATURE CONTROL Displays Unusual
LED Messages .................................................................................................. 6-25
TEMPERATURE CONTROL Displays 20º to 40ºF Higher
than ACTUAL at Ambient Temperature ............................................................. 6-25
TEMPERATURE CONTROL: Erratic or
Does Not Work .................................................................................................. 6-25
Flames Coming From Ends of Ironing Cylinder ....................................................... 6-26
