MegaRAID SAS Software User GuideChapter 7: MegaRAID Storage Manager Window and Menus
| Starting MegaRAID Storage
Manager Software
f
Figure 132: Select Server Window
If the circle in the server icon is orange instead of green, it means that the server is
running in a degraded state—for example, because a drive used in a virtual drive
has failed. If the circle is red, the storage configuration in the server has failed.
NOTE: To access servers on a different subnet, type in the box at the bottom of the
screen the IP address of a server in the desired subnet where the MegaRAID Storage
Manager software is running, and click Update. If you check the Connect to remote
server at: IP address box, you can also access a standalone (remote) installation of
MegaRAID Storage Manager software, if it has a network connection.
NOTE: For the VMWare CIMOM, the server button does not denote the health of the
server. The button is always green regardless of the health of the system.
NOTE: The VMWare server does not show the system health and the operating system
labels. It shows only the Hostname and the IP address of the server.
NOTE: When connecting to a VMWare server on a different subnet, one or more
Frameworks have to be running in the subnet in order to connect to the CIMOM.
2. Double-click the icon of the server that you want to access.
The Server Login window appears, as shown in Figure133.
