MegaRAID SAS Software User GuideChapter 9: Monitoring System Events and Storage Devices
| Configuring Alert Notifications
3. Enter a filename with an .xml extension for the backup configuration (in the format
filename.xml).
4. Click Save.
The drive directory disappears.
5. Click OK.
The backup configuration is saved and the Alert Notification Configuration screen
closes.
9.2.8 Loading Backup
Configurations
You can load all of the values from a previously saved backup into the dialog (all tabs)
to edit or send to the monitor.
NOTE: If you choose to load a backup configuration and the Configure Alerts dialog
currently contains changes that have not yet been sent to the monitor, the changes will
be lost. You are prompted to confirm your choice.
1. On the Alerts Notification Configuration screen, click the Alert Setting tab, Mail
Server tab, or E-mail tab.
2. Click Load Backup.
A message warns that when you load a saved backup file, all unsaved changes
made in the current session will be lost.
3. Click Ye s .
The drive directory appears, from which you can select a backup configuration to
load.
4. Select the backup configuration file (it should be in .xml format).
5. Click Open.
The drive directory disappears.
6. Click OK.
The backup configuration is loaded and the Alerts Notification Configuration screen
closes.
9.2.9 Adding E-mail Addresses of
Recipients of Alert Notifications
The E-mail tab portion of the Alerts Notification Configuration screen shows the e-mail
addresses of recipients of the alert notifications. MegaRAID Storage Manager sends
alert notifications to those e-mail addresses. Use the screen to add or remove e-mail
addresses of recipients, and to send test messages to recipients that you add.
To add e-mail addresses of recipients of the alert notifications, perform the following
steps:
1. Click the E-mail tab on the Event Notification Configuration screen.
The E-mail section of the screen appears, as shown in Figure186.
