Lenze 8200 vector series Mounting Instructions

Extensions for automation
Modules
Mounting and dismounting function modules
6

163
EDK82EV903 DE/EN/FR 5.1
 Note!
ƒ Keep the blanking cover  and the FIF protection cover  so that you can
attach them again after you have dismounted the function module.
– Without the FIF cover , the controller is inhibited.
– If no function module is plugged on, the controller without FIF cover  and
blanking cover  must not be commissioned (dangerous electrical voltage
at the FIF interface).
ƒ When two function modules are operated, make sure that the two
terminals X3/28 (controller inhibit) of the interfaces FIF I and FIF II are
AND’ed internally and must be wired according to their
application.( 166).

Lenze 8200 vector series Specifications

General

Category	DC Drives
Overload capacity	150% for 60 seconds
Protection class	IP20
Mains voltage	380V to 480V AC
Control method	Vector control
Communication options	CANopen
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Humidity	≤ 95% relative humidity, non-condensing
Series	8200 vector
