Connector Connects to Pin no. Signal
J44 Sensor (cover interlock) 1 V24_33V_LD
2+5V_OPEN
3GND
J47 Back USB host port (type A, tall, narrow) 1 VBUSB
2SUB_DM2
3USB_DP2
4GND
J6 LSU, drive and H sync 1 PH_TH_0
2 V24_33v_LD
3 PH_TH_1N
4GND
5V12_DRIVE_OUT0
6GND
7V12_DRIVE_OUT1
JACM1 Sensor (ACM) 1 +5V_ENG_SW
2 S_ACM_SEN_C
3GND
7015
Component locations
