Linksys SPA9000 Administration Guide

Linksys Voice System Administration Guide 152
B
Router Tab
SPA9000 Field Reference
This appendix describes the fields on each page of the SPA9000 administration web server.
After you connect to the SPA9000, you can use the following tabs to open the modules of the
application:
• ”Router Tab,” on page 152
• ”Voice tab,” on page 156
Router Tab
After you click the Router tab, you can choose the following pages:
• ”Status page,” on page 152
• ”Wan Setup page,” on page 153
• ”Lan Setup page and Application page,” on page 156
Router tab >
Status page
You can use the Status page to view information about the SPA9000. The Status page has the
following sections:
• ”Product Information section,” on page 152
• ”System Status section,” on page 153
Router tab > Status page >
Product Information section
Product Name Model number of the SPA9000
Serial Number Serial number of the SPA9000
Software Version Version number of the SPA9000 software
Hardware Version Version number of the SPA9000 hardware
MAC Address MAC address of the SPA9000
Client Certificate Status of the client certificate, which authenticates the SPA9000 for use
in the ITSP network
Customization For an remote configuration (RC) unit, this field indicates whether the
unit has been customized or not. Pending indicates a new RC unit that is
ready for provisioning. If the unit has already retrieved its customized
profile, this field displays the name of the company that provisioned the
unit.

Linksys SPA9000 Specifications

Physical Interfaces

Ethernet ports	2 10/100BaseT RJ-45
Phone ports	2 RJ-11 FXS
Ring voltage	40-55 VRMS
Ring frequency	10 Hz - 40 Hz
Maximum ringer load	3 REN

Power

On-hook voltage	-50 V NOMINAL
Off-hook current	25 mA min
Terminating impedance	Configurable, including 600 ohms
