Linksys SPA9000 Administration Guide

Linksys Voice System Administration Guide 21
2
Upgrading Firmware for the SPA9000
Basic Administration of the SPA9000
Basic Administration of the SPA9000
This chapter introduces you to basic administrative tasks using the SPA9000 administration
web server and the Interactive Voice Response Unit.
For Installation and Configuration of LVS in the most common deployment scenarios, refer to
the Linksys Voice System Installation and Configuration Guide, which is available at Linksys.com.
See the following topics:
• ”Upgrading Firmware for the SPA9000,” on page 21
• ”Connecting to the SPA9000 Administration Web Server,” on page 24
• ”Saving or Discarding Changes SPA9000,” on page 24
• ”Access Levels,” on page 25
• ”Setting Passwords for User and Administrator Accounts,” on page 25
• ”Configuring Basic Settings,” on page 26
• ”Viewing Information about the SPA9000,” on page 33
• ”Viewing Information about Client Stations,” on page 33
• ”Using the Interactive Voice Response Unit,” on page 33
Upgrading Firmware for the SPA9000
As needed, you can download new firmware from Linksys.com and then install the firmware on
the SPA9000.
1. Download the firmware from Linksys.com by completing the following steps:
a. Start a web browser and enter the following address: www.linksys.com.
b. On the menu at the top of the page, choose Support > Technical Support.
c. Click Choose a Product.
d. From the Voice over IP (VoIP) drop-down list, choose IP PBX.
e. On the Choose the Device IP PBX page, choose SPA9000 from the drop-down list on the
left side of the page.

Linksys SPA9000 Specifications

Physical Interfaces

Ethernet ports	2 10/100BaseT RJ-45
Phone ports	2 RJ-11 FXS
Ring voltage	40-55 VRMS
Ring frequency	10 Hz - 40 Hz
Maximum ringer load	3 REN

Power

On-hook voltage	-50 V NOMINAL
Off-hook current	25 mA min
Terminating impedance	Configurable, including 600 ohms
