Linksys SPA9000 Administration Guide

Linksys Voice System Administration Guide 156
Voice tab
Router tab >
Lan Setup page and Application page
Note Linksys Engineering and Quality Assurance strongly advise against
using the SPA9000 as a router. For this reason, the Lan Setup and
Application tabs should not be modified from the default, unused state.
The SPA9000 must only be connected to a switch via the SPA9000
INTERNET RJ45 connector. Do not connect any cable to the SPA9000
ETHERNET port, or you may experience degraded audio performance.
Voice tab
After you click the Voice tab, you can use the following pages:
• ”Info page,” on page 156
• ”Voice tab >,” on page 159
• ”SIP Page,” on page 160
• ”Regional page,” on page 176
• ”FXS 1/2 page,” on page 189
• ”Line 1/2/3/4 page,” on page 196
Voice tab >
Info page
You can use the Info page to view information about the FXS devices and the line interfaces.
This page includes the following sections:
• ”Product Information section,” on page 152
• ”System Status section,” on page 157
• ”FXS 1/2 Status section,” on page 157
• ”Line 1/2/3/4 Status section,” on page 158
• ”Auto Attendant Prompt Status section,” on page 158
• ”Internal Music Status section,” on page 159
VLAN ID The VLAN tag for the VLAN to which the SPA9000 is assigned

Linksys SPA9000 Specifications

Physical Interfaces

Ethernet ports	2 10/100BaseT RJ-45
Phone ports	2 RJ-11 FXS
Ring voltage	40-55 VRMS
Ring frequency	10 Hz - 40 Hz
Maximum ringer load	3 REN

Power

On-hook voltage	-50 V NOMINAL
Off-hook current	25 mA min
Terminating impedance	Configurable, including 600 ohms
