Linksys Voice System Administration Guide 59
Configuring Dial Plans
Configuring Phone Lines and Calling Routing Behavior
dial plan. For more information and examples, see ”Digit Sequences and Functions,” on
page 53.
• Separate each digit sequence with a pipe character, and enclose the entire set of digit
sequences within parentheses. Refer to the following example:
(9,8<:1408>[2-9]xxxxxx | 9,8,1[2-9]xxxxxxxxx | 9,8,011xx. | 9,8,xx.|[1-8]xx)
7. Click Submit All Changes. The phone reboots.
8. If you need to configure a dial plan for any other extensions on the phone (depending on
the model), click the appropriate Extension tab, enter the dial plan, and submit the changes.
9. Click the browser’s Back button to return to the list of phones.
10. Repeat this procedure for each client station that needs a unique dial plan.
11. Verify that you can successfully complete a call using each digit sequence that you entered
in the dial plan.
Note If you hear a reorder (fast busy) tone, you need to review your entries
and modify the dial plan appropriately. See ”Digit Sequences,” on
page 53.
Entering the Line Interface Dial Plan
This dial plan is used to strip steering digits from a dialed number before it is transmitted out to
the carrier.
1. Connect to the SPA9000 administration web server, and choose Admin access with
Advanced settings. (See ”Connecting to the SPA9000 Administration Web Server,” on
page 24.)
2. Click Voice tab > Line N, where N represents the line interface number.
3. Scroll down to the Dial Plan section.
4. Enter the digit sequences in the Dial Plan field.
5. Click Submit All Changes.
Setting the Timers for the Dial Plan
The system uses dial plan timers to determine when a user’s entry (or a null entry) is evaluated.
You can modify the timers for an entire dial plan or for individual sequences within a dial plan.
There are three types of control timers:
• ”Dial Plan Timer (Off-Hook Timer),” on page 60
• ”Interdigit Long Timer (Incomplete Entry Timer),” on page 61
• ”Interdigit Short Timer (Complete Entry Timer),” on page 61
