Linksys Voice System Administration Guide 26
Configuring Basic Settings
Basic Administration of the SPA9000
1. Connect to the SPA9000 administration web server, and choose Admin access with
Advanced settings. (See ”Connecting to the SPA9000 Administration Web Server,” on
page 24.)
2. Click Voice tab > System.
3. In the System Configuration section, enter the Admin Password and the User Password, as
needed. Up to 39 characters are allowed for the passwords.
4. Click Submit All Changes.
Configuring Basic Settings
This section provides information about the following tasks:
”Setting Up the WAN Connection for the SPA9000,” on page 26
”Setting the Date and Time,” on page 27
Configuring Daylight Saving Time,” on page 27
”LAN and Application Guidelines,” on page 28
Configuring Multicast Addressing and Group Paging,” on page 29
Collecting System Logs and Debug Information,” on page 31
Setting Up the WAN Connection for the SPA9000
The SPA9000 becomes a DHCP client of any server on the network. The recommended setting
is to use a static IP address. This configuration provides ease of installation and prevents
connectivity issues that would occur if the IP address of the SPA9000 changed.
1. Connect to the SPA9000 administration web server, and choose Admin access with
Advanced settings. (See ”Connecting to the SPA9000 Administration Web Server,” on
page 24.)
2. Click Router tab > Wan Setup.
3. From the Connection Type drop-down list, choose Static IP.
4. In the Static IP Settings area, enter the Static IP of the SPA9000, as well as the NetMask and
Gateway for your network.
5. In the Optional Settings area, enter the Primary DNS for your network.
NOTE: It is recommended to set an IP address that is outside the address range assigned by
the DHCP server. For example, if the DHCP server assigns IP addresses in the range from
192.168.1.50 to 192.168.1.254, you should select a static IP address between 192.168.1.2
and 192.168.1.49.
6. Click Submit All Changes. The SPA9000 reboots.
