Linksys Voice System Administration Guide 97
6
Using the Internal Music Source for Music On Hold
Configuring Music on Hold
Configuring Music on Hold
This chapter explains how to configure Music on Hold using either a music file or streaming
audio.
This chapter includes the following topics:
• ”Using the Internal Music Source for Music On Hold,” on page 97
• ”Configuring a Streaming Audio Server,” on page 99
Using the Internal Music Source for Music On Hold
The SPA9000 has an internal music source with the user ID imusic that plays an internally
stored music file repeatedly. The SPA9000 ships with a default music file (Romance de Amor).
You can override this file by downloading a new file into the unit by using TFTP.
Refer to the following topics:
• ”Using the Internal Music Source,” on page 97
• ”Changing the Music File for the Internal Music Source,” on page 98
• ”Restoring the Original Music File,” on page 98
Using the Internal Music Source
The SPA9000 has an internal music source that plays an internally stored music file repeatedly.
The SPA9000 ships with a default music file (Romance de Amor).
1. Use the phone menu to find the IP address of the phone:
a. Press the Setup button on the phone keypad.
b. Press 9 - Network, and then scroll down to 2- Current IP Address.
2. Start Internet Explorer, and then enter the IP address of the telephone. The Telephone
Configuration page appears in a separate browser window.
3. Click Admin Login, and then click Advanced.
4. Click the Ext 1 tab.
5. Scroll down to the Call Feature Settings section.
6. Enter the following value in the MOH Server field: imusic
7. Click Submit All Changes.
8. To verify, place a test call to the extension. When the call is answered and put on hold, the
caller should hear the default music file (Romance de Amor).
