Linksys SPA9000 Administration Guide

Linksys Voice System Administration Guide 33
Viewing Information about the SPA9000
Basic Administration of the SPA9000
Viewing Information about the SPA9000
The Router Status page provides information about software version, hardware version, MAC
address, WAN connection type, IP address, and the packets that have been sent and received.
SPA9000 Router > Status
Viewing Information about Client Stations
The PBX Status page provides information about the client stations (IP phones), with hyperlinks
to station configuration pages.
1. Connect to the SPA9000 administration web server, and choose Admin access with
Advanced settings. (See ”Connecting to the SPA9000 Administration Web Server,” on
page 24).
2. To view the status information for the client stations, click the PBX Status link in the top
right corner or lower left corner of the page. The list of client stations appears.
SPA9000 > PBX Status
3. To view the Telephone Configuration page for any station, click the hyperlink in the IP Address
column. For information about the telephone configurations, see the Linksys Phone
Administration Guide.
Using the Interactive Voice Response Unit
In addition to the administration web server, the SPA9000 is equipped with an Interactive Voice
Response unit (IVR) that allows you to perform certain administrative tasks by using an analog
phone that is connected to the SPA9000.

Linksys SPA9000 Specifications

Physical Interfaces

Ethernet ports	2 10/100BaseT RJ-45
Phone ports	2 RJ-11 FXS
Ring voltage	40-55 VRMS
Ring frequency	10 Hz - 40 Hz
Maximum ringer load	3 REN

Power

On-hook voltage	-50 V NOMINAL
Off-hook current	25 mA min
Terminating impedance	Configurable, including 600 ohms
