Linksys Voice System Administration Guide 81
Configuring the SPA400 Network Connection
Administering the SPA400 and Voice Mail Service
NOTE: The user name must be entered exactly as shown: Admin. By default, no password is
required, but a password can be set on the Administration > Management page. See
”Managing Access to the SPA400 Web-Based Configuration Utility,” on page 83.
Configuring the SPA400 Network Connection
The SPA400 becomes a DHCP client of any server on the network. The recommended setting is
to use a static IP address. This configuration provides ease of installation and prevents
connectivity issues that would occur if the IP address of the SPA400 changed.
1. Start Internet Explorer, and enter the IP address of the SPA400.
NOTE: By default, the SPA400 is configured to obtain an IP Address via DHCP. You can check
the obtained IP address on the router DHCP server’s client list.
2. When the password prompt appears, enter the default user name, Admin, with no
password. Then click OK.
NOTE: The user name must be entered exactly as shown: Admin. For information about
managing system access, refer to the LVS Administration Guide.
3. Click Setup tab > Basic Setup.
4. Enter the following settings:
Network Setup section:
• Fixed IP address: Click the radio button, and then enter a valid IP address.
NOTE: To avoid addressing conflicts, enter an IP address that is outside the range of
addresses that are automatically assigned by your DHCP server.
• IP Subnet Mask: Enter the subnet mask for the subnetwork that the SPA400 is on.
• Gateway IP Address: Enter the IP address of the router for this subnetwork.
Domain Name Server (DNS) Address section:
• Primary DNS: Enter the IP address of the primary DNS server.
To Next Page
