Linksys Voice System Administration Guide 85
Configuring a SPA400 to Interoperate with the SPA9000
Administering the SPA400 and Voice Mail Service
Configuring a SPA400 to Interoperate with the SPA9000
A SPA400 must be configured to register the SPA9000. To enable the interoperation of the two
devices, you need to enter corresponding information on the SPA9000 Voice > Line page and on
the SPA400 Setup > SPA9000 Interface page. For voice mail service, additional entries are needed
on the SPA400 Setup > Voicemail Server page.
NOTES:
Complete this procedure for each SPA400, whether it is used as a PSTN gateway or as a
voice mail server.
You also must configure a SPA9000 line interface for this device. See ”Configuring a Line
Interface for a SPA400 (PSTN or Voice Mail),” on page 48.
If you install multiple SPA400 units, keep track of the MAC addresses to ensure that you
know which device you are configuring. In the administration web server, you can see
the MAC address by clicking the Status tab.
1. Connect to the SPA400 administration web server. (See ”Connecting to the SPA400
Administration Web Server,” on page 80.)
2. When the password prompt appears, enter the user name and password. Then click OK.
NOTE: For more information about the administrator account, see ”Managing Access to the
SPA400 Web-Based Configuration Utility,” on page 83.
3. Click Setup tab > SPA9000 Interface.
4. Enter the following settings:
User ID: 9000
This is the user ID that the SPA9000 will use to register with the SPA400. Any ID can be
used, but must match exactly the User ID that you entered on the corresponding
SPA9000 Voice > Line page.
SPA9000 Address: Select the Discover Automatically radio button (required for
SPA9000 operation).
This setting enables the SPA400 to learn the IP address and the UDP port of the SPA9000
the from the SIP Registration packets sent by SPA9000.
Call Signalling Packets: 68
RTP Packets: b8
NOTES:
–Leave the Signalling Port at the default value of 5060. This port is the source port
that is used to originate signaling between the SPA400 and the SPA9000.
