Linksys Voice System Administration Guide 158
Voice tab
Voice tab > Info page >
Line 1/2/3/4 Status section
)
Voice tab > Info page >
Auto Attendant Prompt Status section
Call 1/2 FAX Status of the fax pass-through mode; set to No if this line is used for
voice calls
Call 1/2 Type Direction of the call: Inbound or Outbound
Call 1/2 Remote Hold Indicates whether or not the far end has placed the call on hold: Yes or
No
Call 1/2 Callback Indicates whether the call was triggered by a call back request
Call 1/2 Peer Name Name of the peer, internal station name if local phone, or name acquired
from caller-ID
Call 1/2 Peer Phone Phone number of the other phone involved in the call, either the
extension if a local phone, or the number acquired from caller-ID
Call 1/2 Duration Duration of the call
Call 1/2 Packets Sent Number of packets sent
Call 1/2 Packets Recv Number of packets received
Call 1/2 Bytes Sent Number of bytes sent
Call 1/2 Bytes Recv Number of bytes received
Call 1/2 Decode Latency Number of milliseconds for decoder latency
Call 1/2 Jitter Number of milliseconds for receiver jitter
Call 1/2 Round Trip Delay Number of milliseconds for delay
Call 1/2 Packets Lost Number of packets lost
Call 1/2 Packet Error Number of invalid packets received
Registration State The status of the registration on the line interface: Registered or Not
Registered
Last Registration At Last date and time the line was registered: mm/dd/yyyy hh:mm:ss
Next Registration In Number of seconds before the next registration renewal; example 2672s
Message Waiting Indicates whether you have new voicemail waiting: Yes or No
Mapped SIP Port number of the SIP port mapped by NAT
Field Description
Prompt 1 The duration of the prompt in milliseconds
Prompt 2 The duration of the prompt in milliseconds
Prompt 3 The duration of the prompt in milliseconds
Prompt 4 The duration of the prompt in milliseconds
Prompt 5 The duration of the prompt in milliseconds
Prompt 6 The duration of the prompt in milliseconds
Prompt 7 The duration of the prompt in milliseconds
