Linksys SPA9000 - Page 170

Linksys Voice System Administration Guide 168
Voice tab
Multicast Address IP address (and port number) where the SPA9000 sends control
messages to all the client stations at once. This must be a multicast
address and must contain a port number.
Default: 224.168.168.168:6061.
Group Page Address IP address (and port number) where the SPA9000 tells the client stations
to send and receive group page RTP packets. This must be a multicast
address and must contain a port number.
Default: 224.168.168.168:34567.
Max Expires Sets the maximum allowed Registration expires value in seconds for
client stations. Linksys recommends using a relatively small value, such
as 60 or 120.
Default: 60
Force Media Proxy Forces external client stations to use the SPA9000 Media Proxy when
exchanging RTP traffic with external peers. Linksys recommends using a
relatively small value, such as 60 or 120.
Default: no
Proxy Debug Option Controls what SIP messages to log that are received at or sent from the
Proxy listen port. Choices are as follows: {
none—No logging.
1-line—Logs the start-line only for all messages,
1-line excl. OPT—Same as 1-line but excludes OPTIONS request/
response.
1-line excl. NTFY—Same as 1-line but excludes NOTIFY request/
response.
1-line excl. REG—Same as 1-line but excludes REGISTER request/
response.
1-line excl. OPT|NTFY|REG—Same as 1-line but excludes OPTIONS,
NOTIFY, and REGISTER request/response.
full—Logs all SIP messages in verbose mode.
full excl. OPT—Same as full but excludes OPTIONS request/response.
full excl. NTFY—Same as full but excludes NOTIFY request/response.
full excl. REG—Same as full but excludes REGISTER request/response.
full excl. OPT|NTFY|REG—Same as full but excludes OPTIONS, NOTIFY,
and REGISTER request/response.
Default: None
