NTP-029: Circuit Order 363-206-285
Page 14 of 22 Issue 2, February 2000
DDM-2000 OC-3 MULTIPLEXER
DO ITEMS BELOW IN ORDER LISTED. . . . . FOR DETAILS, GO TO
20.
NOTE:
Wait until FAULT LED on MAIN OLIU extinguishes before
attempting switch.
At Node 1 only, use the switch-line:main:pri=manual
command to switch service to the service line (main-1 OLIU
active-rx at Node 1). (See Figure 10.)
Figure 10 – DDM-2000 OC-3 Point-to-Point to Ring Upgrade
To Next Page
