NTP-059: System Turnup 363-206-285
Page 1 of 12 Issue 3, June 2001
DDM-2000 OC-3 MULTIPLEXER
Establish Release 15 OC-3 or OC-12 Linear
Extension via WaveStar TDM 2.5G OC-48
Backbone Ring
DO ITEMS BELOW IN ORDER LISTED. . . . . FOR DETAILS, GO TO
1.
!
WARNING:
Unterminated optical connectors may emit invisible laser
radiation. Avoid direct exposure to the beam. Do not view
beam with optical instruments. Use of controls or
adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
!
CAUTION:
DDM-2000 circuit packs contain static sensitive components
which can be damaged by electrostatic discharge. A static
ground wrist strap must be worn when handling the circuit
packs. See electrostatic discharge considerations in
Trouble Clearing: TAD-100
.
NOTE:
If the DDM-2000 fails to respond in the indicated manner,
refer to Trouble Clearing: IXL-001.
NOTE:
It is assumed that WaveStar TDM 2.5G shelves in the
system have passed local tests and the WaveStar TDM
2.5G OC-48 ring has been established. It is also assumed
the DDM-2000 OC-3 shelves have been equipped and
tested (363-206-285,
DDM-2000 OC-3 Multiplexer, TARP
Release 13 and Later, User/Service Manual (TOP)—Volume
II
, System Turnup: NTP-016).
NOTE:
This procedure is used to establish an OC-3/OC-12 linear
extension connection to an WaveStar TDM 2.5G OC-48 ring
(See Figure 1). Other configurations may have to be
established to obtain your final configuration.
Determine the network configuration (for example, see Figure 1.)
TAD-100
NTP-016
