Lucent Technologies DDM-2000 OC-3 - Page 2127

363-206-285 Detailed Level Procedure: DLP-512
Issue 2, February 2000 Page 5 of 10
DDM-2000 OC-3 MULTIPLEXER
4. Set options using the syntax of the Commands and Reports section in this
manual.
5. STOP. YOU HAVE COMPLETED THIS PROCEDURE.
Table A – DDM-2000 OC-3 Parameters Provisionable Via the CIT
Parameter Range
Default
(Note1) Command(Note2)
Date current value 70-01-01 set-date
Time current value 00:00:00 set-date
Target ID (system name) 20 characters LT-DDM-2000 set-ne
Remote NE Status enabled,disabled set-ne
Alarm Group 1-255 255 set-ne
Alarm Gateway NE yes,no no set-ne
Shelf number 1-8 1 set-ne
Idle channel signal STS Uneqpd./AIS insert AIS set-ne
VT Uneqpd./AIS insert AIS
CO/RT select CO, RT RT set-ne
CIT page length 0 (pager off), 3-150 rows 24 set-link
PM thresholds See PM Table - set-pmthres
Alarm holdoff delay 0-30 sec 2 set-attr-alm
Alarm clear delay 0-30 sec 15 set-attr-alm
Power minor almn. level MN, MJ MN set-attr-alm
OC1 degrade threshold
10
-5
to 10
-9
10
-6
set-oc1
AIS almn. level of NSA OC-1
Line AIS CR, MJ, MN, NA NA set-oc1
OC3 degrade threshold
10
-5
to 10
-9
10
-6
set-oc3
Sync messaging K byte, S byte, disabled K byte set-oc3
AIS almn. level of NSA OC-3
Line AIS CR, MJ, MN, NA NA set-oc3
DccMode distinct,identical distinct set-oc3
Application 0x1,1+11+1 set-oc3
OC12 degrade threshold§§§
10
-5
to 10
-9
10
-6
set-oc12
Sync messaging§§§ K byte, S byte, disabled K byte set-oc12
AIS almn. level of NSA OC-12
Line AIS§§§ CR, MJ, MN, NA NA set-oc12
DccMode distinct,identical distinct set-oc12
STS-1 path signal
degrade threshold†††
10
-5
to 10
-9
10
-6
set-sts1
Signal fail alarm threshold
10
-3
to 10
-6
10
-3
set-sts1
NSA STS-1 path AIS
alarm level MN, NR MN set-sts1
SA STS-1 path AIS
alarm level CR, MN, NA, NR MN set-sts1
STS-1 channel state*** NMON, AUTO‡ AUTO set-state-sts1
OC-1 line state‡‡‡ NMON, IS IS set-state-oc1
See notes and footnotes at end of table.
