Page #2128 background imageLoading...
Page #2128 background image
DLP-512: Detailed Level Procedure 363-206-285
Page 6 of 10 Issue 2, February 2000
DDM-2000 OC-3 MULTIPLEXER
VT1.5 path signal
degrade threshold***
10
-5
to 10
-9
10
-6
set-vt1
NSA VT path AIS MN, NR MN set-vt1
SA VT path AIS MJ, MN, NA, NR MJ for ring set-vt1
MN for linear
VT channel state*** NMON, AUTO‡ AUTO set-state-vt1
DS3 VMR mode† VMR, VM, clear channel VMR set-t3†
Clear channel DS3 AIS insertion†¶¶ yes, no no set-t3†
DS3 sig failure alm. level† CR, MJ, MN, NA CR set-t3†
DS3 AIS failure alm. level¶¶¶ CR, MJ, MN, NA CR set-t3†
DS3 failure threshold†
10
-3
,10
-6
BER 10
-3
set-t3†
DS3 PM mode† off, on on set-t3†
DS3 PM frame† m13, cbit m13 set-t3†
DS3 PM format† pbit, fmbit, cpbit pbit set-t3†
DS3 X-bits¶¶¶ 1,0 1 set-t3†
DS3 port state† NMON, AUTO‡ AUTO set-state-t3†
DS1 line coding† AMI,B8ZS,noOverride§ noOverride set-t1†
DS1 alarm level† MJ, MN, NA NA set-t1†
DS1 failure threshold†
10
-3
,10
-6
,10
-7
,10
-8
BER 10
-3
set-t1†
DS1 BPV to LOS† yes,no no set-t1†
DS1 AIS insertion† yes, no yes set-t1†
DS1 PM Mode† off, on off set-t1
DS1 PM Format† sf, esf, esfn esf set-t1
DS1 primary port state† NMON, AUTO‡ AUTO set-state-t1†
Environmental alarm level CR, MJ, MN, NA MN set-attr-env
Environmental alarm type 10 characters set-attr-env
Environmental alarm description 26 characters set-attr-env
Control point description 26 characters set-attr-cont
Far end communication over DCC** enabled,disabled enabled set-fecom**
DCC identity for OSI ntwks. userside, networkside see command pgs. set-fecom**
Lanreset y,n n set-fecom**
Porttype cit,tl1 cit set-secu**
synch,asynch synch
Baudrate 1200,2400,4800,9600,19200 9600 set-secu**
Echo enabled,disenabled enabled set-secu**
CIT/DCC security** enabled,disabled,lockout disabled set-secu**
CIT/DCC timeout (minutes)** 0-120 15 set-secu**
SYNC mode switching revertive, nonrevertive revertive set-sync
Sync Timing Source††‡‡ main-1, main-2, fn-c main-1 set-sync
Sync Output Mode§§ ¶ track, lock1, lock2 track set-sync
AIS Threshold level 5, level 4, level 3. level 2 level 5 set-sync
Auto. sync. reconfig. enabled, disabled disabled set-sync
EC-1 alarm level† CR, MJ, MN, NA CR set-ec1
EC-1 degrade threshold†
10
-5
to 10
-9
BER 10
-6
set-ec1
EC-1 port state† NMON, AUTO‡ AUTO set-state-ec1
See notes and footnotes at end of table.
Table A – DDM-2000 OC-3 Parameters Provisionable Via the CIT (Contd)
Parameter Range
Default
(Note1) Command(Note2)
