Lucent Technologies DDM-2000 OC-3 User Manual

363-206-285 Detailed Level Procedure: DLP-512
Issue 2, February 2000 Page 7 of 10
DDM-2000 OC-3 MULTIPLEXER
Feature package ** STS3C, VT PM, or DS1 PM set-feat
Action enabled, disabled disabled set-feat
X.25 packet size 128, 256 256 set-x25
NSAP structure
Organization ID (Operator ID) 6 hex digits 000000 ent-ulsdcc-l3
Reserved (Reserved) 4 hex digits 0000 ent-ulsdcc-l3
Routing Data (Domain) 4 hex digits 00000000 ent-ulsdcc-l3
Routing Data (Area) 4 hex digits 00000000 ent-ulsdcc-l3
Level 2 IS routing enable or disable disable ent-ulsdcc-l3
NSAP structure
TARP lifetime 1 to 65535 100 ent-ulsdcc-l4
NSAP system ID 12 hex digits none ent-ulsdcc-l4
NSAP organization ID 6 hex digits see command pgs. ent-ulsdcc-l4
NSAP reserved field 4 hex digits see command pgs. ent-ulsdcc-l4
NSAP routing domain field 4 hex digits see command pgs. ent-ulsdcc-l4
NSAP routing area field 4 hex digits see command pgs. ent-ulsdcc-l4
TARP timer T1 1 to 3600 secs. 15 secs. ent-ulsdcc-l4
TARP timer T2 1 to 3600 secs. 25 secs. ent-ulsdcc-l4
TARP timer T3 1 to 3600 secs. 40 secs. ent-ulsdcc-l4
TARP timer T4 1 to 3600 secs. 20 secs. ent-ulsdcc-l4
TARP loop detection flush timer 1 to 1440 mins. 5 mins. ent-ulsdcc-l4
TARP data cache enable or disable enable ent-ulsdcc-l4
NSAP system identifier 12 hex digits see command pgs. ent-ulsdcc-l4
TARP data cache ent-ulsdcc-l4
TARP system tid 20 characters see command pgs. ent-ulsdcc-l4
Target identifier 20 characters ent-ulsdcc-l4
TARP organization id 6 hex digits 000000 ent-ulsdcc-l4
TARP reserved 4 hex digits see command pgs. ent-ulsdcc-l4
TARP routing domain 4 hex digits see command pgs. ent-ulsdcc-l4
TARP area field 4 hex digits see command pgs. ent-ulsdcc-l4
Porttype cit,tl1 cit ent-osacmap
synch,asynch synch
VC ckt. type X.25 attach. PVC, SVC PVC ent-osacmap
SNPA: LCN for PVCs LCN, DTE LCN1 to LCN9 (PVC)
or DTE address for SVC see command pgs. ent-osacmap
OS type (ACID) see command pgs. ent-osacmap
ACID (OS type or funct.) see command pgs. ent-tl1msgmap
TL1 message type see command pgs. ent-tl1msgmap
Action to assoc. message
type to OS enabled, disabled enabled ent-tl1msgmap
Cross-connection type twoway, dc, locked twoway ent-crs-sts1
Ring ID for drop&continue m1, m2 see command pgs. ent-crs-sts1
Cross-connection type twoway, dc, locked twoway ent-crs-vt1
Ring ID for drop&continue m1, m2 see command pgs. ent-crs-vt1
See notes and footnotes at end of table.
Table A – DDM-2000 OC-3 Parameters Provisionable Via the CIT (Contd)
Parameter Range
Default
(Note1) Command(Note2)
