Lucent Technologies DDM-2000 OC-3 User Manual

363-206-285 Detailed Level Procedure: DLP-513
Issue 2, February 2000 Page 15 of 20
DDM-2000 OC-3 MULTIPLEXER
21.
NOTE:
It is recommended that a policy be established to set line coding either
using the option switches OR using the set-t1 command. If line code
(lc) parameters are set using the set-t1 command, the circuit pack
switch settings will have no effect. The rtrv-t1 command may be used
to check line code settings.
Refer to Table K and Figure 6 and set the line code option switches, if required.
22. STOP. YOU HAVE COMPLETED THIS PROCEDURE.
Table K – DS1/DS1PM Line Code Settings
Line Code
Format
Switch S1 Settings
S1-4
(Port 1)
S1-5
(Port 2)
S1-6
(Port 3)
S1-7
(Port 4)
S1-8
(Note)
B8ZS OFF OFF OFF OFF
OFF
AMIONONONON
Note: Switch 1, section 8 (S1-8) is unused and ignored by the system.
