DLP-523: Detailed Level Procedure 363-206-285
Page 25 of 30 Issue 2, February 2000
DDM-2000 OC-3 MULTIPLEXER
Figure 6 – BBG6 STS1E Option Settings
Table L – STS1E LBO Settings
Cable Length (Ft)
734A
Cable
735A
Cable LBO Setting
0 to 225 0 to 125 LBO IN
>225 to 450 >125 to 250 LBO OUT
