Lucent Technologies DDM-2000 OC-3 User Manual

DLP-525: Detailed Level Procedure 363-206-285
Page 1 of 10 Issue 2, February 2000
DDM-2000 OC-3 MULTIPLEXER
Install New IMA LAN Software Generic Program
In-Service System
Local Shelf Download
1. Before beginning the software installation, refer to the Software Installation
and Upgrade Procedure section of the Software Release Description. This
section contains a description of any special considerations required when
installing this version of the IMA LAN software.
2.
NOTE:
This procedure is used to install a new IMA LAN software program in a
local in-service DDM-2000 OC-3 shelf. For procedures to download
software to a remote shelf (using ins-prog: or cpy-prog: command),
see DLP-528.
NOTE:
Starting with OC-3 Release 15.0, if an ins-prog: command is issued;
in addition to the TID, the user will be prompted for Program Type with a
value of either nesw (for NE software generic) or lansw (for IMA LAN
software generic).
NOTE:
The new command format is: ins-prog:tid[,pgmtype=lansw];
where the TID entered is that of the shelf where you want to install the
new software.
Verify that no DCC failures or transmission failures (OC-3 LOS, flashing OLIU
FAULT LEDs, etc.) are present on the network element or system receiving the
program.
3.
NOTE:
The PC may be connected to either the front or rear CIT port or remotely
through a dial up modem. If connected to the rear CIT port, a null
modem is needed between the RS-232 cable and the rear CIT port.
Obtain the following equipment:
a. IBM compatible PC running MS-DOS, Release 2.1 or later.
b. RS-232 cable to connect PC COM port to user panel CIT port.
DLP-528
