Grove Published 02-21-2019, Control # 611-05 3-43
TMS9000-2 OPERATOR MANUAL OPERATING CONTROLS AND INDICATORS
The value (2) shows the operating hours, which can be reset.
To reset an individual hour meter use the jog dial to select the
time to reset. The selected function will show the icon
orange.
Pressing Enter with the jog dial will reset the hours to zero. If
the jog dial is used to select the large hourglass at the top
then pressing Enter will reset all the hour timers
The value (8, (Figure 3-38)) shows the number of times that
the pinning system has started and then completed an
unlocking procedure (cylinder unlocking or section
unlocking).
FIGURE 3-40
8882-19*a
1
2
2
2
2
2
2
2
To Next Page
