TMS9000-2 OPERATOR MANUAL LUBRICATION
5
Published 02-21-2019, Control # 611-05
Grove
.
ITEM
NUMBER
LOCATION NAME
APPROX.
CAPACITY
LUBE SPEC NOTES
SERVICE
POINTS
SERVICE
SERVICE
HOURS
BOOM
70
TELESCOPIC SLIDE
FACES
--------------- 01373458 1, 14, 28 8 BRUSH ON
500 HRS/6
MONTHS
71
TELE 1 REAR UPPER
WEAR PAD
--------------- 01373458
1, 14,
27,28,29,34
2LUBE
500 HRS/6
MONTHS
72
TELE 2 REAR UPPER
WEAR PAD
01373458
1, 14,
27,28,30,34
2LUBE
500 HRS/6
MONTHS
73
TELE 3 REAR UPPER
WEAR PAD
01373458
1, 14,
27,28,31,34
2LUBE
500 HRS/6
MONTHS
74
TELE 4 REAR UPPER
WEAR PAD
01373458
1, 14,
27,28,32,34
2LUBE
500 HRS/6
MONTHS
75
TELE 5 REAR UPPER
WEAR PAD
01373458
1, 14,
27,28,33,34
2LUBE
500 HRS/6
MONTHS
76 TELE 5 LOCK PIN --------------- 00554205 1, 14, 28, 34 2 LUBE
250 HRS/3
MONTHS
77 TELE 4 LOCK PIN --------------- 00554205 1, 14, 28, 34 2 LUBE
250 HRS/3
MONTHS
78 TELE 3 LOCK PIN --------------- 00554205 1, 14, 28, 34 2 LUBE
250 HRS/3
MONTHS
79 TELE 2 LOCK PIN --------------- 00554205 1, 14, 28, 34 2 LUBE
250 HRS/3
MONTHS
80 TELE 1 LOCK PIN --------------- 00554205 1, 14, 28, 34 2 LUBE
250 HRS/3
MONTHS
81 TELE-CYLINDER SLED --------------- 01373458
14, 27, 28, 29,
34
5BRUSH ON
500 HRS/6
MONTHS
82
LUFFINGCYL PIVOT
PIN
--------------- 6829003477 1, 8, 14 2 LUBE
100 HRS/
MONTHLY
83
3.6 M SECTION PIVOT
PIN
--------------- 6829003477 1, 8, 14 2 LUBE
100 HRS/
MONTHLY
84
BOOM EXTENSION
SHEAVE
--------------- 6829003477 1 2 LUBE
DURING
REPAIR
85 MAST SHEAVE --------------- 6829003477 1 2 LUBE
DURING
REPAIR
86
BOOM NOSE
SHEAVES
--------------- 6829003477 1 7 LUBE
DURING
REPAIR
87
AUX BOOM NOSE
SHEAVE
--------------- 6829003477 1 1 LUBE
DURING
REPAIR
88
HEAVY BOOM
EXTENSION SHEAVES
--------------- 6829003477 1 2 LUBE
DURING
REPAIR
89
BOOM EXTENSION
SCREW
--------------- 6829003477 1 2 LUBE
DURING
REPAIR
