Megger MFT-X1 User Manual

3. Getting started
This section describes the basic layout of the instrument, the navigation controls and the screen layout that is common
to all measurements. It is strongly recommended the user familiarizes themselves with the full user guide, as there is a
great deal of information on how the measurement works as well as how to get the most from your instrument.
3.1 Quick start (for those in a hurry)
To get going quickly here is a summary of controls and tests.
 Ensure a battery has been fully charged.
 Turn the instrument on by rotating the left rotary knob to the main test mode required. The display will also
show which function is being selected.
 The Hot keys at the top of the display allow each test mode to be customized as required.
 A Hot key with more than two options can be pressed several times to scroll through the options.
 Alternatively, the right range knob can be used to scroll through options very quickly, displaying the options in
an arc similar to the left range knob. Press the required Hot key first then turn the right hand knob.
 The INFO bar at the bottom shows the terminal connections recommended, as below:
Voltage Continuity Insulation Loop
impedance
RCD Earth
resistance
Current
clamp
✓ (1) ✓ ✓ ✓ ✓ ✓ ✓
✓ ✓ (2)
✓ ✓
✓
✓ (3)
Fig 1: Terminal selection table
NOTE :
1. Provides all three voltages on single or 3 phase systems simultaneously.
2. Connecting the neutral provides reverse polarity detection
3. Connection for MCC1010 in current mode
 Depending on the test mode selected the test will either start automatically or require the TEST button to be
pressed as below:
Voltage:
Starts automatically on selection
Continuity:
Starts automatically on selection
Insulation:
Starts when TEST button is held down
Releasing test button stops test
Earth resistance:
Starts when TEST button is pressed and released
Stops automatically on completion of test
Loop Impedance:
Starts when TEST button is pressed and released
Stops automatically on completion of test
RCD:
Starts when TEST button is pressed and released
Stops automatically on completion of test
www.megger.com
MFT-X1
16
Getting started

Megger MFT-X1 Specifications

General

Power Supply	Rechargeable Li-ion battery
Phase Sequence Indication	Yes
Resistance Range	0.01 Ω to 100 kΩ
Protection Rating	IP54
Continuity Testing	0.01 Ω to 2000 Ω
Loop Testing	0.01 Ω to 2000 Ω
RCD Testing	Type AC, A, F, B, and B+
Frequency Measurement	15 Hz to 400 Hz
Insulation Test Voltage	50 V, 100 V, 250 V, 500 V, 1000 V
Voltage Range	12 V to 440 V AC/DC
Frequency Range	15 Hz to 400 Hz
Battery Life	Approximately 8 hours
