15.3 Entering and leaving settings mode
1. Turn the left-hand rotary knob to the SETTINGS position. The display will default to the general options page.
Fig 52: Settings
2. To leave set-up mode, turn the left-hand rotary knob to any position except the SETTINGS position.
3. When you leave SETTINGS mode any changes you have made will be stored, even if you turn the instrument off.
15.4 Selecting a settings page
1. Enter settings mode.
2. The settings screen appears with a row of tabs at the top.
3. Use Hot key 1 and Hot key 5 to highlight the tab for the page where you want to make changes.
4. When the tab for the correct page is highlighted, press Hot key 3 to go to that page.
5. To go to a different page, use Hot key 1 and Hot key 5 to highlight the tab for the new page and press Hot key 3
again.
15.5 General settings
1. Select the general tab.
2. Turn the right-hand knob to highlight the setting you want to change.
The options are :
 Brightness
 Backlight timer
 Contrast mode
 Date
 Time
 Key press beep
 Results beep
 Sleep timer
 Language
 PE confirmation
 Network connection
 Clear network connecting
 Reset to factory setting
3. Press Hot key 3 to confirm your selection or to change the status if it is an ON/OFF function.
