4. Instrument Controls
4.1 Instrument layout
The front panel of your MFT-X1 multifunction tester has four main areas:
2
3
1
4
Item Description Item Description
1 Hot keys 3 Secondary rotary selector knob
2 Primary rotary selector knob 4 Display
9
8
8
5
7
6
Item Description Item Description
5 Hanging strap/neck strap attachment 8 Toolless battery release clips
6 Test lead connection panel 9 Battery info and warnings
7 Li-ION battery module
www.megger.com MFT-X1
17
Instrument Controls
