Megger MFT-X1 - Battery and Fuse Assembly

18.3.1 Battery and fuse assembly
1
3
2
4
5
6
Item Description Item Description
1 Li-ION battery pack 4 2 x Fuses
2 Removable internal cover screw 5 MicroSD card
3 Removable internal cover 6 Spring loaded catches
Replacement battery types are:
 Megger custom Li-ION battery module
www.megger.com
MFT-X1
98
Service and maintenance
