12. Current measurement
WARNING : Current measurements are live circuit tests and all precautions for live working
must be followed.
Fig 37: Current measurement
12.1 General
When used with an optional MCC1010 current clamp, the MFT-X1 can measure AC and TRMS currents.
12.2 Hot keys for current measurements
Hot key 1 Hot key 2 Hot key 3 Hot key 4 Hot key 5
Fig 38: Current Hot keys
Hot key Function Description
1 Clamp setting This setting currently only offers the MCC1010 clamp.
2 Help Press for help on current measurement.
3 Save Press to send the results to a connected Bluetooth
®
device, Refer to 16.
Download results to a remote device on page 89.
4 Not used.
5 Measurement type Press repeatedly to switch between AC and TRMS measurements.
www.megger.com
MFT-X1
48
Current measurement
