B
-
2
VM600 networking manual MAVM600-NET/E
Edition 9
- February 2018
APPENDIX B: AMC8 MODBUS REGISTER DEFINITIONS
Table
B-1:
AMC8 register definitions
Read coil or discrete input re
gisters (Modbus function co
de 01).
Rack
slot
number
(Snum)
Address
offset
(Aoff)
Bit(s)
Channel
Internal value
type
Value
description
Modbus
starting
address
(MSA)
Value
type
CPUM
<7
1
From
3 to 14
0
N/A
Channel 1
Configuration
Alert
−
Low Enable
See
equation
(B.1)
Bit
1
Channel 2
2
Channel 3
3
Channel 4
4
Channel 5
5
Channel 6
6
Channel 7
7
Channel 8
8
Multi-channel 1
9
Multi-channel 2
10
Multi-channel 3
11
Multi-channel 4
12
Channel 1
Alert+ High Enable
13
Channel 2
14
Channel 3
15
Channel 4
16
Channel 5
17
Channel 6
18
Channel 7
19
Channel 8
20
Multi-channel 1
21
Multi-channel 2
22
Multi-channel 3
23
Multi-channel 4
24
Channel 1
Danger
−
Low
Enable
25
Channel 2
26
Channel 3
27
Channel 4
28
Channel 5
29
Channel 6
30
Channel 7
31
Channel 8
32
Multi-channel 1
33
Multi-channel 2
34
Multi-channel 3
35
Multi-channel 4
Same behaviour
173
175
