APPENDIX B: AMC8 MODBUS REGISTER DEFINITIONS
From
3 to 14
144 0-15 Channel 1
Configuration Output Unit
See
equation
(B.1)
U16
145 0-15 Channel 2
146 0-15 Channel 3
147 0-15 Channel 4
148 0-15 Channel 5
149 0-15 Channel 6
150 0-15 Channel 7
151 0-15 Channel 8
152 0-15 Multi-channel 1
153 0-15 Multi-channel 2
154 0-15 Multi-channel 3
155 0-15 Multi-channel 4
Table B-4: AMC8 register definitions
Read holding registers (Modbus function code 04).
Rack
slot
number
(Snum)
Address
offset
(Aoff)
Bit(s) Channel
Internal value
type
Value
description
Modbus
starting
address
(MSA)
Value
type
CPUM
<71
Same behaviour
